Frequency Response: 55Hz to 18kHz with a variation of ±3 dB, and 40Hz to 20kHz with a variation of -10 dB.

Sensitivity (1W/1m): 96dB Sound Pressure Level (SPL).

Nominal Impedance: 8 Ω.

Rated Power (AES): 450W.

Low-Frequency Driver: 12-inch, 75-core woofer.

High-Frequency Driver: 1.75-inch (1-inch throat) compression driver with a 44mm voice coil.

Nominal Coverage Angle (H×V): 80 degrees horizontal by 50 degrees vertical (rotatable, made of high-strength die-cast aluminum).

Maximum Sound Pressure Level (at 1m): 122dB continuous, 128dB peak.

Dimensions (H×W×D)(mm): 602 × 352 × 368.

Weight: 22 kg.

Connection Socket: NEUTRIK four-core speaker socket.

Mounting Hardware: M8 suspension points and 35mm support base.

Connection Method: 1 positive (+) and 1 negative (-).

Enclosure Material: 18mm multi-layer plywood.

Enclosure Surface Coating: Polyurethane spray coating.

Grille: Steel grille with a transparent acoustically resistive dust cover.

酒吧.

KTV包房.

剧院剧场.

舞台返送
